Product Details

1. Product Overview

This high-performance AC axial fan from COOLTRON is engineered for reliable cooling in industrial and commercial applications. With a compact 92x92x25mm form factor, it combines efficient airflow, long service life, and robust protection features to meet demanding operating requirements.

2. Core Specifications

• Dimensions: 92mm (length) × 92mm (width) × 25mm (height)
• Rated Voltage: 115VAC (50/60Hz), Operating Voltage Range: 100-125VAC
• Speed & Airflow: 2700 RPM (50Hz) / 3200 RPM (60Hz) ±10%, 30.0 CFM (50Hz) / 36.0 CFM (60Hz)
• Static Pressure: 4.6 mm-H2O (50Hz) / 6.5 mm-H2O (60Hz)
• Power Consumption: 11W (50Hz) / 9W (60Hz), Rated Current: 0.14A (50Hz) / 0.11A (60Hz)
• Noise Level: 40.0 dB(A) (50Hz) / 45.0 dB(A) (60Hz) (ISO 3745, non-echo chamber)
• Service Life: 80,000 hours at 40℃ (L10, 90% confidence level)

3. Electrical Characteristics

• Motor Protection: Impedance protected
• Polarity Protection: No damage from reverse connection at rated voltage
• Insulation Resistance: ≥100 MΩ (between unshielded wire and frame, 500VDC/min)
• Dielectric Strength: 1500VAC for 1 minute (between terminal and housing)
• Lead Wire: 330mm length from frame edge

4. Environmental Ratings

• Operating Conditions: Temperature -20℃ to +70℃, Humidity 35%-85% RH
• Storage Conditions: Temperature -40℃ to +85℃, Humidity 35%-85% RH
• Packaging Tests: 3-axis (X/Y/Z) 1.1G vibration test (30 mins); 60cm drop test (1 corner, 3 edges, 6 faces)

5. Safety & Compliance

• Certifications: CE (File No.: TB10088274), RoHS compliant
• Labeling: RoHS & date code marked on fan outlet frame; product label includes safety approval, part number, model, rated voltage, current/power, bearing type, motor protection, and location

6. Design & Construction

• Bearing Type: Dual ball bearing for durability
• Blade & Housing: 5-blade thermoplastic PBT (UL 94V-0); die-cast aluminum housing (black painted)
• Rotating Direction: Counter-clockwise (viewed from rotor side)
• Net Weight: 300 grams

7. Usage Notes

• Not suitable for aggressive or corrosive fluid environments
• Avoid pressure on impellers, handling by lead wires, or dropping during installation
• Correct mounting is required to prevent excess resonance, vibration, or noise
• Store per specified temperature/humidity; functional testing recommended for storage over 6 months
• Use a safety guard during testing to prevent personal injury
• All specifications are measured at 25℃, 65% RH under free air and vertical setup
